Wind Power Transformers Built for Cyclic Load and Remote Conditions.

Compact, IEC-compliant wind power transformers up to 6.5 MVA, 33 kV — designed for the tower-base or nacelle, and built to operate reliably in wind farm environments where maintenance access is limited and availability cannot be compromised.

Product Overview

Designed for Where the Wind Blows. Not Where It’s Convenient.

Wind power transformers operate in a fundamentally different electrical and mechanical environment from standard distribution or power transformers. They are subject to cyclic loading as wind speed varies, high ambient humidity and temperature differentials, restricted installation space inside or at the base of the turbine tower, and maintenance intervals measured in months rather than weeks.

KLR Wind Power Transformers are designed specifically for these conditions. The thermal, mechanical, and insulation design accounts for the cyclic load profile of wind generation, the sealing requirements of outdoor and tower-base installation, and the compact dimensional envelope that turbine structures demand.

Technical Specifications

●  Up to 6.5 MVA  Capacity range:

●  Up to 33 kV  Voltage class:

●  50 Hz (designed for variable generation profile)  Frequency:

●  Tower-base or nacelle-mounted configurations  Installation:

●  Enhanced moisture and ingress protection — IP55 / IP65 enclosure options  Insulation:

●  Optimised for partial load and cyclic load operation  Winding:

●  IEC 60076, IEC 61400-1 (wind turbine requirements), grid code compliance as applicable  Standards:

●  ONAN standard; ONAF available for higher ratings  Cooling:

●  Full routine factory tests; vibration and seismic testing available on request  Testing:

Key Features

✓  thermal and insulation system sized for variable wind generation profile, not constant rated load  Cyclic load optimised design

✓  tower-base and nacelle variants designed within turbine structural constraints  Compact footprint

✓  IP-rated enclosures for moisture, dust, and coastal salt-air environments  Enhanced ingress protection

✓  efficiency optimised across the full generation range, not just rated output  Low partial-load losses

✓  meets all wind farm developer and utility interconnection requirements  IEC 60076 and grid code compliance

✓  oil sampling access, pressure relief, and monitoring points positioned for restricted-access sites  Long-interval maintenance design

Applications

●  Utility-scale onshore wind farms — step-up at turbine level

●  IPP wind projects — tower-base or nacelle transformer replacement or new supply

●  EPC contractors for wind energy infrastructure

●  State and private wind energy developers

●  Wind + storage hybrid projects

●  Grid interconnection points for wind farm collector systems

Why KLR for Wind Power Transformers

✓  accounts for the cyclic load profile of wind generation, not just peak rating  Application-specific thermal design

✓  3D SolidWorks design ensures tower-base and nacelle fit without compromising performance  Compact dimensional engineering

✓  part of KLR’s dedicated clean energy transformer range alongside solar inverter duty products  Renewable energy focus

✓  field servicing and oil treatment available for wind farm operators across India  After-sales support

Specify Your Wind Power Transformer.

Share your turbine rating, installation type (tower-base or nacelle), and grid connection voltage — we will provide a technically specified proposal.
